Z-3051HS High-Speed Laser Scanner


    Powerful scanning performance
    Proprietary Z-SCAN+ technology
    Streamlined, rugged and ergonomic design
    LED scan indicator and programmable beeper







مشخصات



OPERATIONAL

Light Source

650 nm visible laser diode (VLD)

Pitch/Roll/Skew Angle

65° / 30° / 65°

Depth of Field

35 – 200 mm (UPC/EAN 100%, PCS=90%)

Scan Angle

52°

Scan Rate

500 scans per second

Minimum Bar Width

5 mil @ PCS=90% (Code 39)

Print Contrast

30% @ UPC/EAN 100%

Indicators (LED)

Three-color LED (green, red & blue)

Beeper Operation

Programmable tone & beep time

System Interfaces

Keyboard, RS-232C, HID USB, wand

PHYSICAL

Dimensions

(L)106.7 × (W)58.0 × (H)155.0 mm (device only)

Weight

148 g (stand excluded)

Cable

Standard 2.0M straight

POWER

Input Voltage

5 VDC ±10%

Operating Current

200 mA

Power Consumption

1.0 watts

REGULATORY

Laser Class

CDRH Class IIa; IEC 60825-1: Class 1

EMC

CE & FCC DOC compliance, VCCI, BSMI

ENVIRONMENTAL

Operating Temperature

0°C – 40°C (32°F – 104°F)

Storage Temperature

-20°C – 60°C (-4°F – 140°F)

Humidity

5% – 95% RH (non-condensing)

Ambient Light Injection

4,500 Lux (fluorescence)

Shock

Designed to withstand 1.0M drops
